IMI Heimeier Dynacon Eclipse heating circuit distributor 934005800, 5 heating circuits
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 100
Details
IMI Heimeier Dynacon Eclipse heating circuit distributor 9340-05.800
5 heating circuits
5 heating circuits
- Application
- underfloor heating systems
- Function:
- Individual room temperature control with actuator or thermostatic head
- Automatic flow control
- shut off
- To fill
- drain
- Wash
- vent
- pressure class:
- PM 6
- Flow range:
- The flow can be infinitely adjusted within the specified range: 30 - 300 l/h.
- Factory setting 300 l/h.
- Differential pressure (ΔpV):
- Max. differential pressure:
- 60kPa (
- Min. differential pressure:
- 30 – 150 l/h = 17 kPa
- 150 – 300 l/h = 25 kPa
- Temperature:
- Max. operating temperature: 70°C
- Minimum operating temperature: -5°C
- Materials:
- Distributor:
- stainless steel 2000 .4301
- Connection fittings: brass, nickel-plated.
- Thermostat upper part:
- Brass
- O-rings: EPDM
- Valve disk: EPDM
- Compression spring: stainless steel
- Thermostatic insert: brass, PPS.
- Spindle: Stainless steel spindle with double O-ring seal. The outer O-ring can be replaced under pressure.
- Flow indicator:
- Heat-resistant plastics and stainless steel. Brass. Dichtungen made of EPDM.
- Filling, draining, flushing and venting device:
- Brass, nickel-plated and plastic. Dichtungen made of EPDM.
