Möhlenhoff Alpha -Basis direct 10 channel, B 50302-10N2 24V Standard - 10 zones: 24 V/230 V, NC/NO, for Stellantriebe 24 V and 230 V, heating

Möhlenhoff Alpha base direct 10 channel, B 50302-10N2 24V

The Alpha Basis direct Standard is the central connection unit of an individual room control system for surface temperature control of heating systems. The Alpha Basis direct is wired with minimal effort to all system components such as controllers and actuators. The system components are supplied directly via the power supply of the Alpha Basis direct. All switching commands of the Controllers are forwarded directly to the connected components via the Alpha base. The standard version has a reduction channel. This can be used to change the room temperature in a time-controlled manner using an external system clock. This version is suitable for systems that are equipped with normally open (NO) or normally closed (NC) components.

• 21 connection terminals for connecting max. 18 Stellantriebe

• Screwless terminal connection technology

• Clearly arranged connection terminals

• Proven cable routing and standard-compliant strain relief

• Equipment for heating systems

• Reduction channel - connection for an external system clock

• Direction of action of the connectable Stellantriebe NC or NO (NC: Normally closed / NO: Normally open)

• Simple, intuitive Plumbing and operation

• High functional reliability

• Maintenance-free

Technical features

• Length: 327 mm
• Width: 94 mm
• Height: 52 mm
• Voltage: 24 + 230 V
• Action: NC + NO
• Zones: 10 zones
