Zehnder Design Bathroom Radiators ZRI01650G500000 RB-160-050, 1567 x 500 mm, blue gray, RAL 7031
Available for order
delivery time: 10-28 working days
Shipping Cost Points: 3200
Details
Zehnder design Bathroom Radiators ZRI01650G500000
- Connection to hot water central heating or for mixed operation
- made of vertically arranged D-profile tubes 30 x 40 mm rounded outwards as well as offset and diagonally arranged flat tubes 70 x 8 mm
- which surround the bathroom radiator
- The resulting recesses on two levels provide space for hanging up several towels
- Additionally, depending on the height, one or two horizontally aligned flat tubes
- D-profile tubes arranged on the side and top as well as square tubes 30 x 30 mm below form a functional Rahmen
- Thermal output according to EN 442
- with CE marking
- with 4 connections at the bottom
- 2x in the middle 2000 /2" for forward/reverse
- Distance 50 mm and 2x 2000 /2"
- outside left and right
- with vent valve
- Bathroom Radiators with powder coating
- standard in color RAL 9016
- in special colors upon request
- Delivered ready for assembly with wall brackets
- Operating pressure max. 4 bar
- Operating temperature hot water central heating max. 110 °C
- inconspicuous consoles hidden behind the collecting pipe
- large pipe spacing
- Mounting accessories in the color of the radiator
